ألوان الهيكل
المواصفات
| Model | 16" x 17" | 18" x 17" |
| Rear wheel size | 24" | 24" |
| Overall Length (mm/in) | 1080 ㎜(42.5 in) | 1080 ㎜(42.5 in) |
| Overall Width (mm/in) | 595 ㎜(23.4 in) | 645 ㎜(25.3 in) |
| Overall Height (mm/in) | 970 ㎜(38.1 in) | |
| Total Weight (kg/lb) | 14.44 ㎏(32.4 lb) | 14.65 ㎏(32.9 lb) |
| Seat Width (mm/in) | 407 ㎜(18.5 in) | 458 ㎜(18 in) |
| Seat Depth (mm/in) | 432 ㎜(17 in) | |
| Seat Height (mm/in) | 495 ㎜-515 ㎜(19.5 in~20.3 in) | |
| Backrest Height (mm/in) | 400 ㎜(15.7 in) | |
| Armrest Height (mm/in) | 220 ㎜-270 ㎜(8.7 in~10.6 in) | |
| Calf Length (mm/in) | 415 ㎜-490 ㎜(16.3 in~19.2 in) | |
| Overall Collapsed Length (mm/in) | 728 ㎜(14") 810 ㎜(24") | |
| Overall Collapsed Width (mm/in) | 320 ㎜(14") 330 ㎜(24") | |
| Overall Collapsed Height (mm/in) | 800 ㎜(31.5 in) | |
| Maximum User Weight (kg/lb) | 115 ㎏(255 lb) | |
| Ship L*W*H(mm/in) | 695 ㎜x310 ㎜x880 ㎜(14") (27.3 inx12.2 inx34.6 in) 825 ㎜x320 ㎜x900 ㎜(24") (32.4 inx12.5 inx35.4 in) |
|
Remark : Karma reserves the right to modify information herein without further notice.
تحميل
UserManual_EN_S-Ergo 300 Series(305)_ver.21
1.57 MB 1 file(s)
