Frame Colors

Specification
Product Model SM-100.3
Nominal seat width(mm) 420
Caster x Rear wheel size (in) 7 x 167 x 22
Maximum user weight(kg) 100
Overall length with legrest(mm) 945980
Overall width(mm) 585 630
Overall height(mm) 875 865
Folded length(mm) 945960
Folded width(mm) 280 310
Folded height(mm)865 865
Total mass(kg) 10.4 11.6
Mass of the heaviest part (kg) 10.4 11.6
Handrim diameter(mm) N/A 485
Horizontal location of axle (mm) 300
Minimum turning radius(mm) 745745
Minimum turning radius without user
(mm)
685 685
Pivot width(mm) 10201115
Static stability downhill(X°) 14 15
Static stability uphill(X°) 1212
Static stability uphill with anti-tippers
(X°)
N/AN/A
Static stability sideways(X°) 16 17
Seat plane angle(X°) 55
Effective seat depth (mm) 470 470
Nominal seat depth(mm) 430430
Effective seat width(mm) 460460
Seat surface height at front edge (mm)
500500
Backrest angle (X°) 1313
Seat to backrest angle(X°) 9999
Backrest height (mm) 400400
Headrest height above seat(mm)N/AN/A
Leg to seat angle(X°) 100100
Footrest to seat distance (mm) 395 ~ 420395 ~ 420
Armrest to seat distance (mm) 235235
Front location of armrest structure (mm)
320320
Manual ver.19


Remark :
* The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
* The actual product specifications may vary according to different configurations.
* Karma reserves the right to modify information herein without further notice.
