Especificación
Product Model Evo LectusEvo Lectus
Seating SystemMinimumMaximum
Nominal seat width (mm/in)* 420 / 17 520 / 21
Nominal seat depth (mm/in)** 400 / 16 600 / 24
Backrest height without cushion (mm) 570 730
Backrest height with cushion (mm) 510670
Headrest height above seat (mm) 730 890
Armrest to seat distance without
cushion (mm)
150 380
Armrest to seat distance with cushion (mm)
70 300
Front location of armrest structure (mm)0 435
Seat surface height at front edge without cushion (mm)450 850
Seat surface height at front edge with
cushion (mm)
530930
Footrest to seat distance without
cushion (mm)
145 550
Footrest to seat distance with cushion (mm)225630
Effective seat width (mm) 420 520
Effective seat depth (mm) 400 600
Seat plane angle (X°) 050
Backrest angle (X°) 590
Seat to backrest angle (X°)95180
Leg to seat angle (X°) 85 180
Driving CharacteristicsMinimumMaximum
Drive wheel size 3.00 - 8 (14")
Rear caster size 2.80/2.50 - 4 (9")
Overall length with legrest (mm) - 1200
Overall width (mm)610660
Overall height (mm) 1115-
Folded length (mm) 935-
Folded width (mm) 610-
Folded height (mm) 770 1115
Total mass (kg) - 165
Total mass without batteries (kg) -123
Mass of the heaviest part (kg) - 120
Maximum user weight (kg)-136
Drive range (km)*** -35.8
Maximum speed forward (km) - 12
Minimum braking distance from max
speed (mm)
1900 -
Obstacle climbing (mm) - 70
Ground clearance (mm) 70-
Minimum turning radius (mm) 750 -
Minimum turning radius without user
(mm)
750 -
Reversing width (mm) 750 -
Static stability downhill (X°) 9
Static stability uphill (X°)9
Static stability sideways (X°) 9
Dynamic stability uphill (X°) 6
Ability to climb rated slope (X°)*** 12
Electrical System
Motor power (W)320
Battery capacity (Ah) 80*2
Charger output current (A) 8
Battery Compartment (L x W x H) (mm) 265 x 175 x 235 (Single Compartment)

Observación: Karma reserva el derecho de modificar la información aquí sin aviso previo.
