Specification
KM-CP33Custom Specification Range
Seat Width (mm)205-380
Seat Depth (mm)230-405
Caster Size (inch)6
Rear Wheel Size (inch)14F / 20F
Seat Height (mm)450
Backrest Height (mm)250-560
Armrest Height (mm)150-330
Calf Length (mm)380-460
Backrest Angle (X°)0-30
Seat Angle (X°)0-40
Legrest Angle (X°)0-40
Max. User Weight (kg)80
Weight W/O Accessories (kg)Min. 9
Total Weight (kg)Min. 11
Overall L x W x H (mm)Min. 830*430*650
Max. 1060*610*960
Overall Collapsed Width (mm)400

Remark : Karma reserves the right to modify information herein without further notice.
