Specification
| Model | KS-200 |
| Dimension (L x W x H mm) | 1040x550x920 mm |
| Weight(Kg),W/I battery | 51.5 kg |
| Weight(Kg),W/O battery | 38.2kg |
| Battery | 12V 22Ah x 2 |
| Charger | 24V 2A |
| Front Tire | 230 x 60 ㎜ solid |
| Rear Tire | 230 x 60 ㎜ solid |
| Driving System | Direct rear wheels (with differential gear) |
| Brake System | Electromagnetic brake |
| Control Method | By speed control lever |
| Top Speed | 6.4km/hr / 4 mph |
| Maximum Climbing Angle | 6°- 8° |
| Cruising range (see note) | 16km / 10 miles |
| Max. User weight | 115 kg / 250 lbs |
Remark : Karma reserves the right to modify information herein without further notice.
