Colores para el Marco
Especificación
| Product Name | KP-31 | KP-31 |
| Seat Width(mm) | 470 | 500 |
| Seat Depth(mm) | 440 | 490 |
| Front Seat Height(mm) | 565 | 555 |
| Backrest Height(mm) | 535 | 535 |
| Seat Angle(X°) | 11 | 7 |
| Back Angle(X°) | 0~56 | 0~47 |
| Armrest Height(mm) | 180 ~ 280 | 175 ~ 272 |
| Legrest Length(mm) | 415 ~ 535 | 390 ~ 530 |
| Motor (W) | 350 | 350 |
| Battery (Ah) | 50 | 50 |
| Battery Compartment L x W x H (mm) | 397.5 x 175 x 170 | 397.5 x 175 x 170 |
| Min. Turning Radius(mm) | 825 (w/o user / 1020 (w/ user) | 825 (w/o user / 1020 (w/ user) |
| Min. Ground Clearance(mm) | 73 | 73 |
| Max Safe Slope | 6° | 6° |
| Max. Obstacle Height(mm) | 50 | 50 |
| Max. Speed(km) | 10 | 10 |
| Max Driving Range (km) | 26 | 26 |
| Max. User Weight(kg) | 136 | 136 |
| Weight w/ Batteries (kg) | 108 | 108 |
| Weight w/o Batteries (kg) | 77.5 | 77.5 |
| Overall L x W x H (mm) | 1060 x 600 x 1210 | 1060 x 625 x 1260 |
Observación: Karma reserva el derecho de modificar la información aquí sin aviso previo.
