Chassis Colors

Anatomic Measurement
Product ModelLeon F Kameleon
Maximum user weight (kg)57
Seating SystemSIZE 1SIZE 2
MinimumMaximumMinimumMaximum
Seat angle (X°)(-3)-(-3)-
Seat angle adjustment/ Power tilt (X°)(-3)42(-3)42
Nominal Seat depth (mm)255395310450
Nominal Seat width (mm)250300350400
Seat surface height (mm)500-500-
Seat height adjustment/ Power lift (mm)500800500800
Backrest angle (X°)(-3)-(-3)-
Backrest angle adjustment/ Manual recline (X°)(-3)48(-3)48
Seat to backrest angle (X°)9114291142
Backrest height (mm)385565465645
Leg to seat angle (X°)89-89-
Leg to seat angle adjustment/ Manual (X°)8917289172
Leg to seat angle adjustment/ Power (X°)8414084140
Footrest length (mm)200420200420
Armrest height (mm)120215230325

Remark :
※ The measurement is based on the body measurement.
※ The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
※ The actual product specifications may vary according to different configurations.
※ Karma reserves the right to modify information herein without further notice.

ISO Standard Measurement
Product ModelLeon F Kameleon
Maximum user weight (kg)57
Driving CharacteristicsMinimumMaximum
Overall length with legrest (mm)10901260
Overall width (mm)620-
Overall height (mm)760820
Folded length (mm)1010-
Folded width (mm)620-
Folded height (mm)760820
Total mass (kg)167 (50Ah)196 (80Ah)
Total mass without batteries (kg)136142
Mass of the heaviest part (kg)116-
Static stability downhill (X°)11
Static stability uphill (X°)10
Static stability sideways (X°)16
Dynamic stability uphill (X°)6
Ability to climb rated slope (X°)12
Maximum speed forward (km)612
Energy consumption (km)25.6 (50Ah)46.2 (80Ah)
Braking methodElectromagnetic Brake
Minimum braking distance from max speed (mm)2000-
Obstacle climbing (mm)-50
Minimum turning radius (mm)660-
Minimum turning radius without user (mm)660-
Reversing width (mm)845-
Ground clearance (mm)60-
Front wheel size3.00 - 8-
Rear wheel size280/250 - 4-
Electrical System
Motor power (W)450
Battery capacity (Ah)50 x 2/ 80 x 2
Charger output voltage (V)24
Charger output current (A)5/ 8
Battery Compartment (L x W x H) (mm)345 x 260 x 220
Seating SystemSIZE 1SIZE 2
MinimumMaximumMinimumMaximum
Seat plane angle (X°)(-3)-(-3)-
Seat angle adjustment/ Power tilt (X°)(-3)42(-3)42
Effective seat depth (mm)275410330470
Effective seat width (mm)250300350400
Seat surface height at front edge (mm)460-460-
Seat height adjustment/ Power lift (mm)460760460760
Backrest angle (X°)(-3)-(-3)-
Backrest angle adjustment/ Manual recline (X°)(-3)48(-3)48
Backrest height (mm)420600500680
Leg to seat angle (X°)89-89-
Leg to seat angle adjustment/ Manual (X°)8917289172
Leg to seat angle adjustment/ Power (X°)8414084140
Footrest to seat distance (mm)160380160380
Armrest to seat distance (mm)150255260365
Front location of armrest structure (mm)05100500

Remark :
※ All the specifications specified in this section are estimated based on the following conditions: 20℃~35℃, an 60 kg occupant, brand new fully charged batteries and driving on the flat road.
※ If you want to know more about the measurement methods of wheelchair specifications, please click the button below to watch the instructions on the Karma website.
※ The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
※ The actual product specifications may vary according to different configurations.
※ Karma reserves the right to modify information herein without further notice.
