|Nominal seat width|
|430 / 18|
|Nominal seat depth (mm/in)**||435 / 18|
|Front casters / Drive wheels size (in)||10 / 12|
|Backrest height (mm)||510|
|Headrest height above seat (mm)||580 ~ 645|
|Armrest to seat distance (mm)||215 ~ 285|
|Seat surface height at front edge (mm)||630 ~ 680|
|Footrest to seat distance (mm)||450 ~ 500|
|Effective seat width (mm)||430|
|Effective seat depth (mm)||435|
|Seat plane angle (X°)||3|
|Backrest angle (X°)||0 ~ 48|
|Seat to backrest angle (X°)||90 ~ 130|
|Overall length with legrest (mm)||1280 ~ 1630|
|Overall width (mm)||680|
|Overall height (mm)||1130 ~ 1360|
|Folded length (mm)||1280|
|Folded width (mm)||680|
|Folded height (mm)||970|
|Total mass (kg)||102.2|
|Total mass without batteries (kg)||70.0|
|Mass of the heaviest part (kg)||48.0|
|Maximum user weight (kg)||135|
|Motor power (W)||550|
|Battery capacity (Ah)||50*2|
|Charger output current (A)||6|
|Drive range (km)***||42|
|Battery Compartment (L x W x H) (mm)||260 x 195 x 210
|Maximum speed forward (km)||15|
|Minimum braking distance from max|
|Obstacle climbing (mm)||75|
|Obstacle climbing (mm)||35|
|Minimum turning radius (mm)||1100|
|Reversing width (mm)||1460|
|Static stability downhill|
|Static stability uphill|
|Static stability sideways|
|Dynamic stability uphill|
|Ability to climb rated slope (X°)***||10|
*Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
**Nominal s eat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
***Drive range/ Ability to climb rated slope are estimated based on the following conditions: 20 ℃~35 ℃, 135/160 kg occupant, brand new fully charged batteries and driving on the flat road.
-The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
-The actual product sp ecifications may vary according to different configurations.
-Karma reserves the right to modify information herein without further notice.
