Casing Colors

Specification
Product ModelKS-737.2L
Nominal seat width
(mm/in)*
480 / 20
Nominal seat depth (mm/in)**495 / 20
Front casters / Drive wheels size (in)10 / 14
Backrest height (mm)550
Headrest height above seat (mm)680 ~ 725
Armrest to seat distance (mm)215 ~ 285
Seat surface height at front edge (mm)590 ~ 640
Footrest to seat distance (mm)505 ~ 555
Effective seat width (mm)480
Effective seat depth (mm)495
Seat plane angle (X°)0
Backrest angle (X°)0 ~ 69
Seat to backrest angle (X°)90 ~ 158
Overall length with legrest (mm)1490 ~ 1945
Overall width (mm)670
Overall height (mm)1115 ~ 1490
Folded length (mm)1365
Folded width (mm)670
Folded height (mm)955
Total mass (kg)133.2
Total mass without batteries (kg)79.2
Mass of the heaviest part (kg)58.0
Maximum user weight (kg)160
Motor power (W)700
Battery capacity (Ah)80*2
Charger output current (A)8
Drive range (km)***63
Battery Compartment (L x W x H) (mm)310 x 170 x 230
(single compartment)
Maximum speed forward (km)15
Minimum braking distance from max
speed (mm)
4400
Obstacle climbing (mm)75
Ground clearance (mm)110
Minimum turning radius (mm)1500
Reversing width (mm)1795
Static stability downhill
(X°)
19
Static stability uphill
(X°)
16
Static stability sideways
(X°)
14
Dynamic stability uphill
(X°)
6
Ability to climb rated slope (X°)***10

Remark:
*Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
**Nominal s eat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
***Drive range/ Ability to climb rated slope are estimated based on the following conditions: 20 ℃~35 ℃, 135/160 kg occupant, brand new fully charged batteries and driving on the flat road.
-The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
-The actual product sp ecifications may vary according to different configurations.
-Karma reserves the right to modify information herein without further notice.
