User-Adjustable Backrest
No tools required. The user can manually adjust the backrest to three different angles: 5, 10, 15 degrees. The armrests are pivotally connected to the backrest and move with the backrest for more comfort and support.
Foldable Push-bar
The push bar strengthens the wheelchair frame and provides attendants with an ergonomic surface to more comfortably and efficiently maneuver the wheelchair, also alleviate the fatigue that can come with pushing a wheelchair.
Compact and Portable
The ergonomic arm-pads are curved inward according to the way users lean their arms and elbow on the pad. The pad is also narrower at the bottom edges, creating less obstruction for the hands while propelling.
Durable Double Cross Bar Frame
The frame is designed to last longer than an ordinary wheelchair. The double cross-bar holds the entire wheelchair structure firmly and protects the safety of the user on the road.
Outrigged Armrests
Spacious and comfortable, the outrigged design minimizes the chair’s overall width while still maintaining an ergonomic sitting space.
Modern Look
When it comes to the style, you can mix and match the frame color (pearl silver) with the classic gray or orange upholstery.
Frame Colors
Upholstery Colors
Colors represented on our website are for reference only. Please contact your local provider for actual color samples.
Optional Accessories
Specification
Manual Wheelchair Measurement Method
| Product Model | S-Ergo 106 (KM-1501.3) |
| Nominal seat width (mm/in)* | 450 / 18 |
| Nominal seat depth (mm/in)** | 430 / 17 |
| Front caster / Rear wheel size (in) | 7 / 24 |
| Backrest height (mm) | 430 |
| Headrest height above seat (mm) | N/A |
| Armrest to seat distance (mm) | 230 |
| Front location of armrest structure (mm) | 350 |
| Seat surface height at front edge (mm) | 500 |
| Footrest to seat distance (mm) | 360 ~ 435 |
| Effective seat width (mm) | 465 |
| Effective seat depth (mm) | 510 |
| Seat plane angle (X°) | 7 |
| Backrest angle (X°) | 12 |
| Seat to backrest angle (X°) | 95 |
| Leg to seat angle (X°) | 98 |
| Overall length with legrest (mm) | 1005 |
| Overall width (mm) | 630 |
| Overall height (mm) | 920 |
| Folded length (mm) | 975 |
| Folded width (mm) | 310 |
| Folded height (mm) | 735 |
| Total mass (kg) | 14.9 |
| Mass of the heaviest part (kg) | 10.5 (24Q) 14.3 (24F) |
| Maximum user weight (kg) | 115 |
| Minimum turning radius (mm) | 830 |
| Minimum turning radius without user (mm) | 705 |
| Pivot width (mm) | 1190 |
| Static stability downhill (X°) | 18.5 |
| Static stability uphill (X°) | 10.0 |
| Static stability sideways (X°) | 17.5 |
| Handrim diameter (mm) | 520 |
| Horizontal location of axle (mm) | 0 |
Manual ver.30
* Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
– The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
– The actual product specifications may vary according to different configurations.
– Karma reserves the right to modify information herein without further notice.
