Frame Colors

Specification
Model16" x 17"18" x 17"
Rear wheel size24"24"
Overall Length
(mm/in)
1080 ㎜(42.5 in)1080 ㎜(42.5 in)
Overall Width (mm/in)595 ㎜(23.4 in)645 ㎜(25.3 in)
Overall Height
(mm/in)
970 ㎜(38.1 in)
Total Weight (kg/lb) 14.44 ㎏(32.4 lb) 14.65 ㎏(32.9 lb)
Seat Width (mm/in)407 ㎜(18.5 in)458 ㎜(18 in)
Seat Depth (mm/in)432 ㎜(17 in)
Seat Height (mm/in)
495 ㎜-515 ㎜(19.5 in~20.3 in)
Backrest Height
(mm/in)
400 ㎜(15.7 in)
Armrest Height
(mm/in)
220 ㎜-270 ㎜(8.7 in~10.6 in)
Calf Length (mm/in) 415 ㎜-490 ㎜(16.3 in~19.2 in)
Overall Collapsed
Length (mm/in)
728 ㎜(14") 810 ㎜(24")
Overall Collapsed
Width (mm/in)
320 ㎜(14") 330 ㎜(24")
Overall Collapsed
Height (mm/in)
800 ㎜(31.5 in)
Maximum User
Weight (kg/lb)
115 ㎏(255 lb)
Ship L*W*H(mm/in)695 ㎜x310 ㎜x880 ㎜(14")
(27.3 inx12.2 inx34.6 in)
825 ㎜x320 ㎜x900 ㎜(24")
(32.4 inx12.5 inx35.4 in)
Manual Ver.21


Remark : Karma reserves the right to modify information herein without further notice.
