ERGO 3 Transferring Ergonomic Wheelchair

Ergo 3

Elevate Your Comfort with Next-Gen Lightweight Ergonomic Mobility

At its core, the Karma Ergo Series combines ergonomic excellence and lightweight mobility. Now it takes a leap forward by creating a natural balance that spans from head to shoulders, down to the lower back. This clever design frees users from the effort of maintaining an upright head position, enhancing their social life with more joy and vitality.

At the heart of this transformation lies the patented Ergo Back and market-proven S-Ergo Seat. Discover the future of seating luxury with the Ergo 3 – where form, function, and well-being converge in perfect harmony.

Product inquiry

Advanced Ergo Seating System

Senior wheelchair users tend to have weaker upper body control which leads to slouched posture or downward-facing head position. The Ergo Seating System addresses this common issue by incorporating scientifically proven seating angles, effectively promoting equilibrium in body posture. This innovative design is tailored to passively seated individuals in wheelchairs, facilitating an expanded field of vision, elevating social interactions, and mitigating chronic sitting discomfort.

Why do you need seating system

KARMA Technology

S-Ergo Seating System

The S-Ergo Seating is globally patented in many countries. The seating provides the wheelchair user with basic pressure relief without having to purchase a foam cushion. While a foam cushion can be cumbersome and pricey, the S-Ergo Seating frame is lightweight and simple, offering the short-term wheelchair user an inexpensive option.

Modern Look

When it comes to the style, you can mix and match the frame color ( black and pearl) with the below upholstery. Rose Red only combined with Gray or Dark Gray Upholstery.

Frame Colors

Upholstery Colors

Colors represented on our website are for reference only. Please contact your local provider for actual color samples.

Optional Accessories

Product Model	Ergo 3
Nominal seat width (mm/in)*	410 / 16	460 / 18	510 / 20	410 / 16	460 / 18	510 / 20	410 / 16	460 / 18	510 / 20
Nominal seat depth (mm/in)**	430 / 17	430 / 17	430 / 17	430 / 17	430 / 17	430 / 17	430 / 17	430 / 17	430 / 17
Front caster / Rear wheel size (in)	6 / 14 7 / 14	6 / 14 7 / 14	6 / 14 7 / 14	6 / 20 7 / 20	6 / 20 7 / 20	6 / 20 7 / 20	7 / 24	7 / 24	7 / 24
Backrest height (mm)	435	435	435	435	435	435	435	435	435
Headrest height above seat (mm)	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A
Armrest to seat distance (mm)	220	220	220	220	220	220	220	220	220
Front location of armrest structure (mm)	360	360	360	360	360	360	360	360	360
Seat surface height at front edge (mm)	435 485	435 485	435 485	435 485	435 485	435 485	435 485	435 485	435 485
Footrest to seat distance (mm)	335 ~ 435	335 ~ 435	335 ~ 435	335 ~ 435	335 ~ 435	335 ~ 435	335 ~ 435	335 ~ 435	335 ~ 435
Effective seat width (mm)	420	470	520	420	470	520	420	470	520
Effective seat depth (mm)	430	430	430	430	430	430	435	435	435
Seat plane angle (X°)	6	6	6	6	6	6	6	6	6
Backrest angle (X°)	20	20	20	20	20	20	20	20	20
Seat to backrest angle (X°)	102	102	102	102	102	102	102	102	102
Leg to seat angle (X°)	110	110	110	110	110	110	110	110	110
Overall length with legrest (mm)	1050 ~ 1080	1050 ~ 1080	1050 ~ 1080	1050 ~ 1080	1050 ~ 1080	1050 ~ 1080	1050 ~ 1080	1050 ~ 1080	1050 ~ 1080
Overall width (mm)	580	630	680	600	650	700	600	650	700
Overall height (mm)	865 915	865 915	865 915	865 915	865 915	865 915	865 915	865 915	865 915
Folded length (mm)	710	710	710	760	760	760	800	800	800
Folded width (mm)	310	310	310	330	330	330	330	330	330
Folded height (mm)	690 740	690 740	710 760	690 740	690 740	710 760	690 740	690 740	710 760
Total mass (kg)	11.4	12.4	12.7	12.4	13.4	13.7	12.9	13.9	14.2
Mass of the heaviest part (kg)	7.9 (14Q) 10 (14F)	8.6 (14Q) 10.7 (14F)	8.9 (14Q) 11 (14F)	7.9 (20Q) 11 (20F)	8.6 (20Q) 11.7 (20F)	8.9 (20Q) 12 (20F)	7.9 (24Q) 11.5 (24F)	8.6 (24Q) 12.2 (24F)	8.9 (24Q) 12.5 (24F)
Maximum user weight (kg)	115	115	115	115 / 125	115 / 125	115 / 125	115 / 125	115 / 125	115 / 125
Minimum turning radius (mm)	900 ~ 925	900 ~ 925	900 ~ 925	900 ~ 925	900 ~ 925	900 ~ 925	900 ~ 925	900 ~ 925	900 ~ 925
Minimum turning radius without user (mm)	780 ~ 800	780 ~ 800	780 ~ 800	780 ~ 800	780 ~ 800	780 ~ 800	780 ~ 800	780 ~ 800	780 ~ 800
Pivot width (mm)	1000 ~ 1220	1000 ~ 1220	1000 ~ 1220	1000 ~ 1220	1000 ~ 1220	1000 ~ 1220	1000 ~ 1220	1000 ~ 1220	1000 ~ 1220
Static stability downhill (X°)	14	14	14	14	14	14	14	14	14
Static stability uphill (X°)	14	14	14	14	14	14	14	14	14
Static stability sideways (X°)	15	15	15	15	15	15	15	15	15
Handrim diameter (mm)	N/A	N/A	N/A	430	430	430	520	520	520
Horizontal location of axle (mm)	40	40	40	30	30	30	20	20	20

* Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
– The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
– The actual product specifications may vary according to different configurations.
– Karma reserves the right to modify information herein without further notice.
