Power Positioning Functions

Modular Power Elevating Seat

The MGN-KIS-L can elevate the seat up to 30 cm, helping the user reach things easier or get a better view.

Modular Power Tilt

The MGN-KIS-T is a power tilt seating system that uses the Tilt-in-Space function to tilt the chair from 0° to 47°. Tilting the body back will shift weight to the user’s back thus shifting pressure away from the hipbones and redistributing it over a larger surface area. This feature helps reduce the risk of developing pressure ulcers and avoid back pain.

Modular Power Recline and Power Articulating Legrest

The MGN-KIS-R offers the ability to recline the backrest 0°-80°. This allows users to stretch their hip joints and relax the back muscles. The power articulating legrest extends in length as is elevated to provide optimal comfort and support.

Frame Colours

Specification
Product ModelMGN-KIS (Adult)MGN-KIS (Pediatric)
Nominal seat width
(mm)*
410/435/460/485/510310/335/360/385/410
Nominal seat depth
(mm)**
410~510310~410
Front caster size (in)8
Drive wheel size (in)14
Rear caster size (in)6
Backrest height with
cushion (mm)
510~560410~460
Armrest to seat distance
with cushion (mm)
200~300150~250
Seat surface height at front edge with cushion
(mm)
440~515 (without powered tilting, reclining and lifting) /
460~540 (with powered tilting only) /
485 ~785 (with tilting and lifting)
Footrest to seat
distance with cushion
(mm)
330 ~480(adult)240~350
Seat plane angle (X°)0/3/6(without powered tilting, reclining and lifting) /
-6/-3/0/3/6( with powered tilting only)
Backrest angle (X°)0~30(manual) / 0~80 (powered reclining)
Manual/ Powered Tilt,
Recline (X°)
Powered Tilting:0~45(T) ;0~45(LT)
Manual Reclining:0~30
Powered Reclining:0~80
Overall Length (w/wo
legrest)* Width* Height
(mm)
1170/940*650*1215~1295 (without powered tilting and lifting)/
1170/940*650*1215~1295 (with powered tilting )/
1170/940*605*1240~1540 (with powered lifting and tilting)
Total Weight(W/
Batteries)
Total mass (kg)
117 (without powered tilting and lifting)/
124 (with powered tilting )/
141 (with powered lifting and tilting )
Total mass without
batteries (kg)
87 (without powered tilting and lifting)/
94 (with powered tilting )/
111 (with powered lifting and tilting )
Maximum user weight
(kg)
136 (adult)
ControllerVR2/ R-net (optional)
Motor power (W)450
Battery capacity (Ah)50* 2
Drive range (km) ***25
Maximum speed
forward (km/h)
6/10/12
Obstacle climbing (mm)50
Minimum turning radius
(mm)
725675
Dynamic stability (X°)6
Electric ver.11


Remark :
* Nominal seat width is known by measuring the width of seat cushion at 120 mm in front of the backrest. This value is mainly used in the product ordering process.
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
*** Drive range is estimated based on the following conditions: 20℃~35℃, 136 kg occupant, brand new fully charged batteries and driving on the flat road.
– The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
– The actual product specifications may vary according to different configurations.
– KARMA reserves the right to modify information herein without further notice.
