Specification
Manual Wheelchair Measurement Method
| Model | SM-150.5(F16") | SM-150.5(F22") | ||
| Nominal seat width(mm) | 400 | 450 | 400 | 450 |
| Caster x Rear wheel size (in) | 7 x 16 | 7 x 22 |
||
| Maximum user weight(kg) | 100 | 100 | ||
| Overall length with legrest(mm) | 920 | 975 | ||
| Overall width(mm) | 595 | 650 | 625 | 680 |
| Overall height(mm) | 880 | 880 | 875 | 875 |
| Folded length(mm) | 840 | 840 | 955 | 955 |
| Folded width(mm) | 300 | 300 | 300 | 300 |
| Folded height(mm) | 775 | 775 | 760 | 760 |
| Total mass(kg) | 10.5 | 10.8 | 11.4 | 11.7 |
| Mass of the heaviest part (kg) | 10.3 | 10.6 | 11.2 | 11.5 |
| Minimum turning radius(mm) | 680 | 720 | ||
| Pivot width(mm) | 1000 | 1140 | ||
| Seat plane angle (X°) | 7 | 5 | ||
| Effective seat depth (mm) | 470 | 480 | ||
| Nominal seat depth(mm) | 410 | 440 | ||
| Effective seat width(mm) | 420 | 470 | 430 | 480 |
| Seat surface height at front edge (mm) | 500 | 480 | ||
| Backrest angle (X°) | 13 | 11 | ||
| Seat to backrest angle(X°) | 95 | 97 | ||
| Backrest height (mm) | 385 | 390 | ||
| Leg to seat angle(X°) | 95 | 96 | ||
| Footrest to seat distance (mm) | 460 ~ 510 | 395 ~ 445 | ||
| Armrest to seat distance (mm) | 220 | |||
| Front location of armrest structure (mm) | 330 | 335 | ||
Manual ver.04
Remark :
* The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
* The actual product specifications may vary according to different configurations.
* Karma reserves the right to modify information herein without further notice.
Download
SM-100.5_SM-150.5_UserManual_EN_ver.04
944.93 KB 1 file(s)
