What is ERGO LITE for?
Manual Wheelchair Measurement Method
|Product Model||Ergo Lite (KM-2501)|
|Nominal seat width (mm/in)*||400 / 16||450 / 18|
|Nominal seat depth (mm/in)**||430 / 16||430 / 16|
|Front caster / Rear wheel size (in)||6 / 14||6 / 14|
|Backrest height (mm)||420||420|
|Headrest height above seat (mm)||N/A||N/A|
|Armrest to seat distance (mm)||210||210|
|Front location of armrest structure (mm)||310||310|
|Seat surface height at front edge (mm)||480||480|
|Footrest to seat distance (mm)||395 ~ 410||395 ~ 410|
|Effective seat width (mm)||400||450|
|Effective seat depth (mm)||420||420|
|Seat plane angle (X°)||5||5|
|Backrest angle (X°)||11||11|
|Seat to backrest angle (X°)||96||96|
|Leg to seat angle (X°)||102||102|
|Overall length with legrest (mm)||930||930|
|Overall width (mm)||560||610|
|Overall height (mm)||905||905|
|Folded length (mm)||830||830|
|Folded width (mm)||275||280|
|Folded height (mm)||700||710|
|Total mass (kg)||8.6||8.8|
|Mass of the heaviest part (kg)||8.6||8.8|
|Maximum user weight (kg)||100||100|
|Minimum turning radius (mm)||670||670|
|Minimum turning radius without user (mm)||740||740|
|Pivot width (mm)||1050||1050|
|Static stability downhill (X°)||16||16|
|Static stability uphill (X°)||11.5 (with anti-tippers)||11.5 (with anti-tippers)|
|Static stability sideways (X°)||16||16|
|Handrim diameter (mm)||N/A||N/A|
|Horizontal location of axle (mm)||5||5|
* Nominal seat width is measured the width of seat cushion at 120mm in front of the backrest. This value is mainly used in the product ordering process.
** Nominal seat depth is measured from the front end of the seat cushion to the back cushion. This value is mainly used in the product ordering process.
– The actual product specifications differ from the data in the table by ±1 cm ±0.5 kg.
– The actual product specifications may vary according to different configurations.
– Karma reserves the right to modify information herein without further notice.
How ERGO LITE has impacted lives
Get in Touch with KARMA Medical
Crash Test Approved
The Ergo Lite is approved for transportation in accordance with ISO 7176-19. This means it is suitable to be used as a seat in a motor vehicle for transportation.
