Power Positioning Functions

Modular Power Elevating Seat

The LEN-KIS-L can elevate the seat up to 30 cm, helping the user reach things easier or gain a better view.

Modular Power Tilt

The LEN-KIS-T is a power tilt seating system that uses the Tilt-in-Space function to tilt the chair from 0° to 47°. Tilting the body back will shift weight to the user’s back thus shifting pressure away from the hipbone and redistributing it over a larger surface area. This feature helps reduce the risks of developing pressure ulcers and avoid back pain.

Modular Power Recline and Articulating Legrest

The LEN-KIS-R is a power recline seating system that offers the ability to recline the backrest from 0° to 80°. This allows the users to stretch their hip joints and relax the back muscles. The power articulating legrest extends in length as it is elevated to provide optimal comfort and support.

Casing Colors

Product NameLEN-KIS(Adult)LEN-KIS (Junior)
Seat Width410mm~510mm310mm~410mm
Seat Depth410mm~510mm310mm~410mm
Front Seat Height510mm 310mm~410mm
Front Seat Height
400mm~515mm( manual) /
460mm~540mm(manual, with tilting option) /
485mm~785mm(powered, with lifting and tilting options)
Backrest Height510mm~560mm410mm~460mm
Seat Angle0°~6°，three settings for incremental adjustments in increments of
3°. /
-6°~6°， four settings for incremental adjustments in increments of
3°. (with tilting option) /
Not adjustable ( with lifting and tilting options)
Back Angle0°~30°(Manual) /
0°~80°(Powered)
Armrest Height200mm~300mm150mm~250mm
Leg rest Length330mm~480mm240mm~350mm
Manual/Powered TiltTilt：0°~45°(with tilting option) /
Tilt：0°~45°(with lifting and tilting options)
Suspension4 shock absorber
Motor(Nominal Output)DC 24V 450W
Batteries50Ah * 2pcs /
60 or 70Ah * 2pcs (optional)
ControllerVR2 or R-net
Caster Wheel 230mm (9”) )Pneumatic Tire ( optional PU tire)
Rear Wheel 355mm(14”) Pneumatic Tire 14”(optional PU tire)
Max Safe Slope6°
Max. Speed6km/hr (Germany) / 10km/hr / 12km/hr
Range25 km
Maximum Obstacle Climbing
Ability 		50mm
Turning Radius900mm850mm
Overall Length(w/wt legrest)
* Width* Height(w/wt head
support)		1080/850mm*650mm*1215/1295mm/
1080/850mm*650mm*1215/1295mm(with tilting option)/
1080/850mm*650mm*1240/1540mm(with lifting and tilting options)		960/850mm*650mm*1095/1175mm
960/850mm*650mm*1095/1175mm(with tilting option)
960/850mm*650mm*1120/1420mm(with lifting and tilting options)
Max. User Weight136 kg100 kg
Weight (W/O Batteries)109/106kg (without batteries) /
116/113kg (without batteries, with tilting option) /
133/130kg (without batteries, with lifting and tilting options )
Electric ver.10


Remark :
※ The total weight with batteries will vary depending on the battery used in each local market.
※ Karma reserves the right to modify information herein without further notice.
